overview:
The user can access D-Lite Cloud from the web to manage and congure o-site locations.
The internet tra c does not pass through the cloud, compliant with the latest data protection and privacy regulations.
Security is assured with out-of-band, SSL-encrypted management plane backed with a 99.99% uptime service level agreement.
If the Cloud service is down this will not a ect the service of local locations.
Technical Specications:
General
Interfaces:
• IEEE 802.11ax Wi-Fi 6
• 1 x 10/100/1000 Mbps Ethernet Port
• 1 x 10/100/1000/2500 Mbps Ethernet PoE Port
Standards :
• IEEE 802.11a/b/n/g/ac/ax
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
• IEEE 802.3at Power over Ethernet (PoE)
• IEEE 802.11h(DFS)
• IEEE 802.3i/u/ab
• IEEE 802.3x Flow Control
• IEEE 802.11e(WMM)
• IEEE 802.11k/v/r
LEDs : Power/Cloud
Antenna :
Internal omni-directional Wi-Fi antennas
– 2 x 3 dBi 2.4GHz
– 4 x 5 dBi 5GHz
Maximum Output Power:
2.4 GHz: 20 dBm
5 GHz: 23 dBm
Data Signal Rate :
2.4 GHz: Up to 573.5 Mbps2
5 GHz: Up to 4802 Mbps2
Frequency:
2.4 GHz: 2.4~2.4835GHz
5GHz: 5.150~5.350GHZ
Modulation Schemes:
OFDM – BPSK,QPSK, 16-QAM, 64-QAM 256-QAM 1024-QAM
DSSS – DBPSK, DQPSK, CCK
functionality
Security Features:
192-bit Enterprise encryption
Latest 802.11 128-bit AES with SAE
128-bit Enterprise encryption
802.11 128-bit AES
MAC address ltering
RADIUS server authentication
SSID isolation
Guest isolation
Captive portal
Station isolation
Maximum SSIDs:
Supports up to 16 SSIDs per device: Up to 8 SSIDs per wireless band
physical
Dimensions: 220 x 220.6 x 39mm (Without Mounting Kits), 220 x 220 x 44mm(With Mounting Kits)
Weight : 0.8kg
Power Input :
IEEE 802.3at Power over Ethernet (PoE) on LAN 1
Power adapter: 12 V DC, 2 A
Power Consumption : Upto 17W
Temperature:
Operating: 0°C to 40 °C
Storage: -30 to 70 °C
Humidity:
Operating: 5% to 95% non-condensing
Storage: 5% to 95% non-condensing
Mean Time Between Failure (MTBF) : >400,000 hours
Mounting Options :
Ceiling mount
Wall mount
Desktop (horizontal)
Certications: CE Class B , FCC Class B , UL-2043 , IC Class B
Network Management:
Web (HTTP/HTTPs)
D-Lite Cloud Management
D-Lite App Management
AP Cluster Management
Stand-alone Mode
