• 2.5G Ethernet Connectivity.
• USB-C Connector.
• Auto Speed Detection.
• Supports Crossover Detection.
• Supports Full-Duplex Mode.
• Two LED indicators.
• No power adapter required.
• Bundled with a virtual CD for driver installation (for Windows).
• Backwards compatible (10/100/1000 Mbps).

Technical Specifications
General
Device Interfaces

• RJ-45 Ethernet Port (10/100/1000/2500 Mbps), USB-C Connector

LED

• Connection (orange), Link/ACT (flashing white)

Functionality
IEEE Standard

• IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

USB Specifications

• USB 3.1 Gen 1, USB 3.0, USB 2.0

Supports

• IEEE 802.1P (Layer 2 Priority Encoding)
• IEEE 802.1Q (VLAN tagging)
• IEEE 802.3az (Energy Efficient Ethernet)
• IEEE 802.3bz (2.5GBASE-T)
• IEEE 802.3x (Full Duplex flow control)

Software
Auto Speed Detection

• 10/100/1000/2500 Mbps

Crossover Detection

• Auto-MDI/MDI-X

Power Management

• Power Saving Mode when Ethernet cable is unplugged

Hot Pluggable

• Yes

System Requirements Windows

• 7/8/10, Mac OS 10.6 or later

Physical
Operating Mode Power Consumption

• 250 mA

Standby Mode Power Consumption

• 60 mA

Cable Length

• 160 mm (6.3 in)

Dimensions

• 53 x 21.5 x 15 mm (2.1 x 0.8 x 0.6 in)

Weight

• 28.5 g (1.0 oz)

Operating Temperature

• 10 to 45 °C (50 to 113 °F)

Storage Temperature

• 10 to 70 °C (14 to 158 °F)

Operating Humidity

• 10% to 85% non-condensing

Storage Humidity

• 5% to 90% non-condensing

Certifications

• CE, FCC, IC
