CLA04-UC6-XXXX LinkBasic Installation Cable U/UTP CAT. 6 (305M)

In Stock
Highlights:

نظرا للتغير المستمر في سعر العملة يرجى مراجعة الشركة  أولا في سعر الشراء قبل اتمام عملية الشراء على رقم واتساب 01224077567

Description

CLA04-UC6 is an unshielded twisted pair (U/UTP) category 6, designed for constructing external structural networks.It consists of four pairs twisted on a cross-shaped core insert, wrapped with polyester foil.
The diameter of one-strand wires made of 100% copper is 0.565mm (23AWG). The length of the cable is 305m.
The wire insulation is made of high-density polyethylene (HDPE) with high mechanical resistance. The diameter of an insulated conductor is 1.02mm.
The top coat is gray RAL7035 and it is made of polyvinyl chloride. The outer diameter of the cable is 6.2mm.
Parametrs of CLA04-UC6 are confirmed by the certificate of the Institute of Communications.

FEATURES

  • A twisted pair designed for internal installations.
  • A one-strand conductor made of 100% copper.
  • Diameter of wires – 0.565mm.
  • Insulation of wires – HDPE.
  • Diameter of insulated conductor – 1.02mm.
  • The colour of the top coat is gray RAL7035.
  • Outer diameter of the cable – 6.2mm.
  • Length counter printed at every meter of the cable.
  • Certificate of the Institute of Communications.
  • Compliant with UL, EIA/TIA 568B.2-10, ISO/IEC 11801.
  • Package: carton.

SPECIFICATION

  • Application: Internal.
  • Construction: U/UTP.
  • Category: 6.
  • Cable length: 305m (1000ft).
  • Construction of wires: One Stand.
  • Conductor material: Copper (CU).
  • Diameter of wires: 0.565mm (23AWG).
  • Insulation of wires: HDPE.
  • Diameter of insulated wires: 1.02mm.
  • Number of pairs: 4.
  • Pair colours:
      • White and blue / Blue.
      • White and orange / Orange.
      • White and green / Green.
      • White and brown / Brown.
  • Coat: PVC.
  • Outer diameter of the cable: 6.2mm.
  • The colour of the outer coat: Grey RAL7035.
  • Wave impedance:
      • 100±15? @ 0.772-100MHz.
      • 100±22? @ 200-250MHz.
  • Effective capacitance @ kHz: Max. ?5.6nF/100m.
  • Propagation speed: 65%.
  • Insulation resistance: Min. 5000M?/km.
  • Working temperatures: 20~70°C.
  • Additional information:
      • Certificate of the Institute of Communications.
      • Length counter printed at every meter of the cable.
  • Package type: Carton.
  • Net weight: kg.
