overview
Advanced Hardware to Power Reliable, Scalable Networks
Up to 5× WAN ports with USB and SFP deliver versatile internet access. Multi-WAN Load Balancing intelligently distributes data streams according to each port’s bandwidth, maximizing multi-line broadband efficiency for faster, more reliable connectivity.**
High-Security and High-Performance VPN
IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE§ /SSL VPN easily build secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study in distributed environments.
SD-WAN for Multi-Site Connectivity
Connect branch offices to headquarters in just a few clicks-no complex VPN setup required. Centralized management delivers reliable site-to-site connectivity and seamless scalability as the network grows.△
Intelligent Protection and Performance Secure Your
Network with Ease
Intelligent DPI & Content Filtering
DPI delivers precise application identification and intelligent traffic control to keep your network at peak performance, and Content Filtering offers flexible category- and time-based rules, simplifying internet management and facilitating the enforcement of policies for employees or families.
Proactive Threat Defense
Enhance threat detection and defense with the integrated IDS/IPS engine. Benefit from continuous protection with an extensive attack prevention signature database, featuring over 4,000 regularly updated signature rules.
Always-On DoS/DDoS Protection
Automatically detect and block Denial of Service (DoS) attacks, including TCP/UDP/ICMP Flooding, Ping of Death, and related threats, ensuring uninterrupted network performance.
Empowering Businesses with Reliable Omada SDN Solutions
Omada’s Software-Defined Networking (SDN) solution seamlessly integrates access points (APs), managed switches, and gateways, enabling 100% centralized cloud management for a highly scalable network.
specifications:–
SECURITY
IDS/IPS: Signature-based IPS/IDS threat detection
Access Control:
• Source/Destination IP Based ACL
• Stateful ACL
• IPv4/IPv6 ACL
• National Based ACL
• FQDN
DPI:
• Deep Packet Inspection
• Support 2421 type Applications
DNS Proxy: DNSSEC, DoH, DoT, DNS Override, and DNS Cache
Filtering:
• Web Group Filtering§
• URL Categoroies and URLs Filtering
• Web Security§
Attack Defense:
• TCP/UDP/ICMP Flood Defense
• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN
ARP Inspection:
• Sending GARP Packets
• ARP Scanning§
• IP-MAC Binding
• ARP Detection
VPN
GRE: √ (Only in Standalone Mode)
SSL VPN: 50 Tunnels
IPsec VPN:
• 100 IPSec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
• IPsec Failover
• IKE v1/v2
• MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)
PPTP VPN:
• PPTP VPN Server
• PPTP VPN Client (10)※
• 50 Tunnels
• PPTP with MPPE Encryption
L2TP VPN:
• L2TP VPN Server
• L2TP VPN Client (10)※
• 50 Tunnels
• L2TP over IPSec
OpenVPN :
• OpenVPN Server
• OpenVPN Client (5)※
• 55 OpenVPN Tunnels
• “Certificate + Account” Mode
• Full Mode
WireGuard VPN: √
SD-WAN: √
HARDWARE FEATURES
Standards and Protocols: IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q,TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP, LLDP
Interface:
• 1 Gigabit SFP WAN/LAN Port
• 1 Gigabit WAN Port
• 4 Gigabit LAN/WAN Ports
• 1 USB 3.0 Port (supports USB LTE dongle and USB storage)
Network Media:
• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m); EIA/TIA-568 100Ω STP (Max 100 m)
• 100BASE-TX: UTP category 5, 5e cable (Max 100 m); EIA/TIA-568 100Ω STP (Max 100 m)
• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
Fan Quantity: Fanless
Button: Reset Button
Power Supply: 12V/1A DC Power Adapter
PoE Budget: –
Flash: 128 MB NAND
DRAM: 512 MB DDR4
LED: PWR, SYS, SFP, USB, WAN (1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act)
Dimensions ( W x D x H ): 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
Protection: 4 kV surge protection
Enclosure: Steel
Mounting: Desktop/Wall/Rackmount
Max. Power Consumption:
7.5 W (with USB 3.0 connected)
4.5 W (without USB 3.0 connected)
PERFORMANCE
Concurrent Session: 150,000
New Sessions /Second: 4,600
NAT (Static IP): 945.3 Mbps / 940.5 Mbps
NAT(DHCP): 939.6 Mbps / 940.9 Mbps
NAT(PPPoE): 943.6 Mbps / 940.9 Mbps
NAT (L2TP): 908.6 Mbps / 918.4 Mbps
NAT (PPTP): 906.2 Mbps / 915.9 Mbps
66 Byte Packet Forwarding Rate: 1,453,489 pps / 1,453,488 pps
1,518 Byte Packet forwarding rate: 81,279 pps / 81,275 pps
IPsec VPN Throughput:
• ESP-SHA1-AES256: 885.3Mbps
• ESP-SHA256-AES256: 844.8 Mbps
• ESP-SHA384-AES256: 868.5 Mbps
• ESP-SHA512-AES256: 849.5 Mbps
GRE:
Unencrypted: 1094.2 Mbps
Encrypted: 702.2 Mbps
WireGuard VPN: 341.3 Mbps
OpenVPN: 139.1 Mbps
L2TP VPN Throughput:
Unencrypted: 1422.4 Mbps
Encrypted: 686.2 Mbps
PPTP VPN Throughput:
Unencrypted: 1356.1 Mbps
Encrypted: 205.1 Mbps
SSL VPN Throughput: 131.6 Mbps
DPI Throughput:
TCP: 933 Mbps
UDP: 927 Mbps
IPS Throughput:
TCP: 918 Mbps
UDP: 920 Mbps
Management Features
Omada App: Yes. Requires the use of Omada Hardware Controller, Omada Central (Cloud-Based), or Omada Software Controller.
Centralized Management:
• Omada Central (Cloud-Based)
• Omada Hardware Controller
• Omada Software Controller
Cloud Access: Yes. Requires the use of Omada Hardware Controller, Omada Central (Cloud-Based), or Omada Software Controller.
Service: Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
Maintenance:
• Web Management Interface
• Remote Management
• Export & Import Configuration
• SNMP v1/v2c/v3
• Diagnostics (Ping & Traceroute)
• NTP Synchronize§
• Port Mirroring
• CLI (only in Standalone Mode)
• Syslog Support
• Speedtest
Zero-Touch Provisioning: √
Management Features:
• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration
BASIC FUNCTIONS
LAN DNS: √
WAN Connection Type:
• Static IP
• Dynamic IP
• PPPoE(supports MRU Configuration)
• PPTP
• L2TP
MAC Clone: Modify WAN/LAN MAC Address†
DHCP:
• DHCP Server
• DHCPv6 PD Server (only in Standalone Mode)
• DHCP Options Customization
• DHCP Address Reservation
• Multi-IP Interfaces
• Multi-Net DHCP
• WAN DHCP 60
Stateful ACL: √
Quality of Service: √
Bridge VLAN: √
IPv6: StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address mode
VLAN: 802.1Q VLAN
IPTV: IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Advanced Features
Advanced Routing:
• Static Routing
• Policy Routing
• RIP§
• OSPF§
Bandwidth Control: IP-based Bandwidth Control
Load Balance:
• Intelligent Load Balance
• Application Optimized Routing
• Link Backup (Timing, Failover)
• Online Detection
NAT:
• One-to-One NAT
• Multi-Net NAT
• Port Forwarding
• Port Triggering§
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP
• Disable NAT
Session Limit: IP-based Session Limit
AUTHENTICATION
Web Authentication:
• No Authentication
• Simple Password
• Hotspot (Local User /Voucher‡/ SMS‡/Radius‡)
• External Radius Sever
• External Portal Sever
• LDAP§
OTHERS
Certification: CE, FCC, RoHS
Package Content:
• ER7206
• Power Adapter
• Quick Installation Guide
• Rackmount Kit
System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10
MAC OS, NetWare, UNIX or Linux
Environment:
• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 90% non-condensing
