New

TL-SG1210P TP-link10-Port Gigabit Desktop Switch with 8-Port PoE+

EGP3,980.00

20% Off
Close
Price Summary
  • EGP5,000.00
  • EGP3,980.00
  • 20%
  • EGP3,980.00
  • Overall you save EGP1,020.00 (20%) on this product
In Stock
Highlights:
  • 9 10/100/1000Mbps RJ45 ports, 1 Gigabit SFP port
  • With 8 PoE+ ports, transfers data and power on one single cable
  • Works with IEEE 802.3af/at compliant PDs and expands office network
  • 802.1p/DSCP QoS enable smooth latency-sensitive traffic
  • High PoE power budget with up to 30W for each PoE port and 63W for all PoE ports
  • Up to 250 m data and power transmission range under Extend Mode**
  • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive applications
  • Isolation Mode allows one-click client traffic separation for higher security and performance
  • Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery
  • Easy to use, with no configuration and installation needed
Description

Overview

  • The TL-SG1210P provides 9 10/100/1000Mbps RJ45 ports and 1 Gigabit SFP port. Port 1 to port 8 of the switch support IEEE 802.3af/at compliant PDs with up tp 30 W for each PoE port and total PoE power budget of 63 W*. The TL-SG1210P is an unmanaged switch with desktop design, outstanding performance and quality, which is a great selection for expanding your network.

Power over Ethernet

  • 8 IEEE 802.3af/at compliant PoE+ ports, with a total PoE power budget of 63 W*
  • Flexible deployment for PoE suppoted devices such as wireless access points (APs), IP cameras and IP phones
  • Designed to use a single Ethernet cable for both data and power transmission, lowering infrastructure costs

Gigabit Expansion Solution

  • 9 10/100/1000Mbps RJ45 ports and 1 Gigabit SFP port provide up to 20 Gbps Switching Capacity
  • IEEE 802.3x flow control provides reliable data transfer

Highlight Performance

  • 802.1p and DSCP QoS ensures smooth traffic
  • IGMP Snooping optimizes multicast applications
  • Up to 250 m data and power transmission range under Extend Mode**
  • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive applications
  • Isolation Mode allows one-click client traffic separation for higher security and performance
  • Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery
  • Fanless design ensures quiet operation

Easy to Use

  • Just plug & play, no configuration required
  • Auto MDI/MDIX eliminates the need for crossover cables
  • Auto-negotiation intelligently adjusts for compatibility and optimal performance

Specifications

Model

  • TL-SG1210P

Standards

  • IEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.3af, 802.3at, 802.3z, 802.1p

Network Ports

  • 8 PoE+ 10/100/1000Mbps RJ45 Ports
  • 1 10/100/1000Mbps RJ45 Port
  • 1 Gigabit SFP Slot

Network Media(Cable)

  • 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
  • 100Base-TX: UTP category 5, 5e or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
  • 1000Base-T: UTP category 5, 5e, 6 or above cable(maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
  • 1000BASE-X MMF, SMF

PoE

PoE Standard:

  • 802.3 af/at PoE Ports 1-8, up to 30 W per port

PoE Power Budget

  • 63 W*

Auto Negotiation

  • YES

Auto MDI/MDIX

  • YES

Max Power Consumption

  • 7.0 W (220/50Hz. no PD connected)
  • 77.24 W (220/50Hz. with 63W PD connected)

Max Heat Dissipation

  • 23.87 BTU/h (no PD connected)
  • 263.39 BTU/h (with 63W PD connected)

Forwarding Mode

  • Store and Forward

Switch Capacity

  • 20 Gbps

MAC Address Table

  • 4K, Auto-learning, Auto-aging

Extend Mode

  • Yes (Ports 1-4)

Priority Mode

  • Yes (Ports 1-2)

Isolation Mode

  • Yes (Ports 1-4/5-8)

PoE Auto Recovery

  • Yes (Ports 1-8)

Flow Control

  • YES

Fanless

  • YES

LED

  • Power, Link/Act, PoE Status, PoE MAX

Dimensions

  • 8.2 x 5.0 x 1.0 in. (209 × 126 × 26 mm)

Certifecation

  • CE, FCC

Operating Temperature

  • 0°C to 40 °C (32 °F to 104°F )

Storage Temperature

  • -40 °C to 70 °C (-40 °F to 158°F )
