D-Link’s centralized management solution for Small-to-Medium-Sized Business (SMB) networks. Nuclias Connect makes it easier to analyze, automate, configure, optimize, scale, and secure your network — delivering the convenience of an Enterprisewide management solution, at an SMB price. DAP-2620 converts any Ethernet wall socket into a high-speed dualband AC Wave 2 Wi-Fi access point. Integrating a simplistic Gigabit Ethernet-to-Wireless design, wired interface, and a phone line
connection, the DAP-2620 delivers simultaneous, dual-band, 2×2 MIMO technology for small, medium, and enterprise networks.

Solution Features:

• Free-to-Download Nuclias Connect Management Software
• License-Free Access Points
• Backwards-Compatibility
• Intuitive Interface
• Inexpensive Hardware Controller*
• Traffic Reporting and Analytics
• Remote Configuration and Batch Configuration.
• Multi-Tenant and Role-based Administration
• Searchable and Auditable Event and Change Logs
• 802.1x and RADIUS Server, POP3, LDAP
• Multilingual Support
• Front-Desk Ticket Management
• Authentication and Payment Gateway (Paypal)
• Integration via Customizable Captive Portal
• Dual-band throughput of up to 1167Mbps
• IEEE 802.11ac Wave 2 wireless
• 2 x 2 MU-MIMO over two spatial streams
• 1 x Gigabit Ethernet port
• Phone line port for voice communications
• IEEE 802.3af Power over Ethernet (PoE) for tidier, less-wires setup
• Supports WPA2™ – WiFi security for more protection
• MAC Filtering and WLAN Partitioning
• Quality of Service (QoS) prioritizes network traffic, minimizing the impact of busy bandwidth
• Supports up to 16 SSIDs
• Wall plate design that easily blends into surroundings

Solution Benefits:

• Network-Wide Management

Free to download to a Windows server (or Linux via Docker) or PC, the Nuclias Connect software currently supports a dozen new and legacy D-Link Access Point (AP) models, and is capable of managing up to one thousand APs without the need for additional licensing charges, coupled with a local lite management Smartphone app and an inexpensive optional hardware controller (The Hub*) suitable for remote locations where a dedicated PC or server might be impractical.

• Flexibility to Meet Your Needs

Through software-based monitoring and remote management of all wireless Access Points (APs) on your network, Nuclias Connect offers tremendous flexibility compared to traditional hardware-based management systems. Configuration can be done remotely. Management software is customizable, and enables control and analytics of a broad or fine granularity, presentable in a variety of formats. Additionally, admins can provide and manage a variety of distributed deployments, including the option to configure settings and admin accounts in a specific manner for each deployment. Nuclias Connect gives you the financial and technical flexibility to expand from a small network to a larger one (up to 1,000 APs), while retaining a robust and centralized management system.

• Easy Administration

Nuclias Connect supports multi-tenancy, so network admins can grant localized management authority for local networks. In addition, because APs can support eight SSIDs per radio, administrators have the option of using one SSID to create a guest network for visitors. Nuclias Connect allows for multiple user authentications and also makes it possible to configure specific access controls for each SSID, giving admins the option of configuring separate internal networks for different subnets. This means that more advanced Value-Added Services, such as Captive Portal or Wi-Fi Hotspot, can be used to help manage wireless network traffic

• Insights at a Glance

Gain an extensive understanding of your network through usage analytics and status reports which can be viewed at a glance. Insights derived from traffic data can create business value. Traffic can be viewed across the entire network, to the level of a single AP.

• Network Security and Data Privacy

Nuclias Connect balances the need for access convenience with the need for security. All communications over the system are encrypted (WPA2/WPA31), with your user data never leaving your possession. Additional security measures (such as firewalls) can also be added to your network, without undue technical difficulty.

• Technical Specifications

General:

Device Interfaces

• 1 x IEEE 802.11a/b/g/n/ac Wave 2 wireless 2
• 1 x Gigabit LAN (supports PoE)
• 1 x RJ11 phone line portStandards
• IEEE 802.11a/b/g/n/ac 2
• IEEE 802.3u/ab
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
• IEEE 802.3af Power over Ethernet

Antennas

• 2 x internal dual-band 2 dBi omni antennas

Operating Frequency 3

• 2.4 GHz band: 2.4 to 2.4835 GHz
• 5 GHz band: 5.15 to 5.30 GHz

Maximum Output Power(EIRP)

• 2.4 GHz band: 19 dBm
• 5 GHz band: 20 dBmData Signal Rate
• 2.4 GHz band: Up to 300 Mbps 2
• 5 GHz band: Up to 867 Mbps 2

Functionality:

Security

• WPA-Personal
• WPA-Enterprise
• WPA2-Personal
• WPA2-Enterprise
• WEP 64/128-bit encryption
• SSID broadcast disable
• MAC address access control
• Internal RADIUS server

Network Management

• D-Link Nuclias Connect
• Telnet
• Secure Telnet (SSH)
• Web (HTTP)
• Secure Socket Layer (SSL)
• Traffic control

LEDs

• Power/status

• Physical:

Dimensions

• 153.3 x 94.65 x 35.8 mm (6.04 x 3.73 x 1.41 in)

Weight

• 212 g (0.47 lbs) without mounting base
• 250.9 g (0.55 lbs) with mounting basePower Supply
• External power adapter: 12 V/1 A

IEEE 802.3af PoE

Maximum Power Consumption

• 8W

Temperature

• Operating: 0 to 40 °C (32 to 104 °F)
• Storage: -20 to 65 °C (-4 to 149 °F)Humidity
• Operating: 10% to 90% non-condensing
• Storage: 5% to 95% non-condensingMeantime Between Failure (MTBF)
• > 30,000 hours

Certifications

• FCC
• CE4
